SME1 heavy duty duplexer
- ※Structural features:
★The surface of the heating plate is ground, the width of the heating plate is 600mm, there are 20 heating plates in total, and the cooling and shaping length is 5 meters.
The heating plate is made of container plate, with pressure...
- Inquiry Hotline: 13903279305
-
Product Details
※Conventional technical parameters:
1. Maximum working width: 2500mm >3. Maximum mechanical speed: 250m/min 4. Temperature requirement: 160—200℃ Steam pressure: 0.8-1.3MPa
5. Air source Pressure: 0.6—0.9MPa 6. Cooling and shaping length: 5 meters Number of heating plates: 20 pieces
※Roll diameter parameters:
1 、 Diameter of upper driving rubber roller: ￠800mm Diameter of lower driving rubber roller: ￠600mm Outsourcing wear-resistant rubber
2. Front driven belt roller Diameter: ￠215mm Diameter of post-forming driven belt roller: ￠215mm
3. Diameter of pressing roller: ￠70mm Diameter of shaping roller: ￠86mm
4. Diameter of upper belt tension roller: ￠155mm >Note: All roller surfaces are hard chrome plated after grinding.
※Power motor and electrical parameters:
1. Main drive motor power: 90KW variable frequency motor 380V 50Hz continuous (S1 ) working system
1. Maximum working width: 2500mm >3. Maximum mechanical speed: 250m/min 4. Temperature requirement: 160—200℃ Steam pressure: 0.8-1.3MPa
5. Air source Pressure: 0.6—0.9MPa 6. Cooling and shaping length: 5 meters Number of heating plates: 20 pieces
※Roll diameter parameters:
1 、 Diameter of upper driving rubber roller: ￠800mm Diameter of lower driving rubber roller: ￠600mm Outsourcing wear-resistant rubber
2. Front driven belt roller Diameter: ￠215mm Diameter of post-forming driven belt roller: ￠215mm
3. Diameter of pressing roller: ￠70mm Diameter of shaping roller: ￠86mm
4. Diameter of upper belt tension roller: ￠155mm >Note: All roller surfaces are hard chrome plated after grinding.
※Power motor and electrical parameters:
1. Main drive motor power: 90KW variable frequency motor 380V 50Hz continuous (S1 ) working system
